This plain rectangular strip of synthetic fabric impregnated with thermosetting

resin provides a cost-effective and easyto- use alternative to traditional materials

such as phosphor bronze or lead.

Special features

Self-lubricating to provide low dynamic and breakout friction.

High resistance to wear.

Suitable for heavy-duty applications.

High strength material that offers long life and damping of mechanical vibrations to reduce plant downtime.

Versatile and easy to assemble.

Typical applications

Often used in conjunction with compacttype piston head seals in hydraulic systems to eliminate metal-to-metal contact and other problems associated with offset pistons.

Operating capabilities

Maximum bearing stress at RT (static duty): 400MPa (58,015psi).

Maximum bearing stress at RT (dynamic duty): 90MPa (13,053psi).

Temperature range: -60°C to +100°C (-76°F to +212°F); or +130°C (+266°F)

with severely restricted load carrying capacity on dynamic duties.

aximum recommended relative

velocity: 1.0m/s (196.9fpm).

Materials of construction

Synthetic fabric impregnated with thermosetting resin.

Tape thickness

Tape thickness varies according to tape width. Note that thin strip dissipates heat

more efficiently and therefore the thermal expansion will be less.

Bearing strip cutting

The standard type of cut is 45° scarf split. Other types of cut are available

on request.
